| Place of Origin: | China |
| Certification: | ISO9001:2015 |
| Model Number: | 4×8 mesh |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25 kg / kraft paper bag, 100 kg / large bag 150 kg / sealed iron drum |
| Delivery Time: | Negotiable |
| Payment Terms: | L/C;T/T |
| Supply Ability: | 6000 ton/year |
| Product Name: | 4×8 Mesh 13X Molecular Sieve Desiccant | Classification: | Chemical Auxiliary Agent |
|---|---|---|---|
| CAS: | 1318-02-1 | Purity: | 99% |
| Usage: | Petroleum Additives, Water Treatment Chemicals | Model Number: | 13X |
| MF: | Na2O, Al2O3, SiO2 | Advantage: | Strong Adsorption Capacity, High Strength |
| Diameter: | 3.6-4.8mm | Wear Rate(%): | ≤0.25 |
| High Light: | 4×8 mesh 13X Molecular Sieve Desiccant,3.6mm 13X Molecular Sieve Desiccant,3.6mm 13x zeolite |
||
3.6mm 4×8 Mesh 13X Molecular Sieve Desiccant
Product introduction
13X molecular sieve has a pore size of 10A, which can adsorb molecules smaller than 10A. Any molecule that can be adsorbed on 3A, 4A, and 5A molecular sieves can be adsorbed by 13X. It can be used for catalyst carrier, water and carbon dioxide co-adsorption, water and hydrogen sulfide gas co-adsorption, It is mainly used in the drying of medicine and air compression systems. There are different professional varieties according to different applications. 13X-APG special molecular sieve for air separation is a special molecular sieve produced to meet the special requirements of the cryogenic air separation industry, further improve the adsorption capacity of molecular sieve for carbon dioxide and water, and avoid freezing tower phenomenon in the air separation rectification process. This product is suitable for For cryogenic air separation devices of various sizes.
Molecular formula: Na2O.Al2O3 .2.45SiO2.6.OH2O
Application
Purifying the gas in the air separation device, removal of H2O, CO2 and hydrocarbons; natural gas, liquefied petroleum gas, liquid alkanes (propane, butane) dehydration and desulphurization (removal of H2S and thiol); general gas (such as compressed air, permanent gases) depth drying; ammonia synthesis gas drying and purifying; aerosol, propellant desulfurization and deodorization; pyrolysis gas removal of CO2; catalyst carrier; water and carbon dioxide coadsorption; water and hydrogen sulfide gas coadsorption etc.
13X molecular sieve technical Index:
| Index Item | Unit | Technical index | |||
| Shape | APG4×8 mesh | APG6×8 mesh | APG8×12 mesh | hp8×12 mesh | |
| Diameter | mm | 3.6-4.8 | 2.4-3.5 | 1.7-2.4 | 1.7-2.4 |
| Size ratio up to grade | % | ≥98 | ≥98 | ≥98 | ≥98 |
| Bulk density | g/ml | ≥0.64 | ≥0.64 | ≥0.65 | ≤0.65 |
| Wear rate | % | ≤0.20 | ≤0.25 | ≤0.20 | ≤0.25 |
| Crushing strength | N | ≥85 | ≥50 | ≥26 | ≥24 |
| Static water adsorption | % | ≥ | ≥25 | ≥25 | ≥25 |
| Carbon dioxide adsorption | % | ≥18 | ≥18 | ≥18 | ≥19.3 |
| Package water content | % | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Store
Room temperature, relative humidity not greater than 90% indoors: avoid water, acid, alkali, isolate air, and store in airtight.
Regeneration
Removal of water: dry gas such as nitrogen, air, hydrogen, saturated hydrocarbon, etc. can be heated to 150-320°C and pass into the molecular sieve bed under 0.3-0.5kg/m2 pressure for 3-4 hours, and then to the adsorber Pass in dry cold air for about 2-3 hours, isolate the air and cool to room temperature.
Removal of organic matter: the adsorbate can be replaced from the molecular sieve with water vapor, and then heated to (1). The regeneration can also be regenerated by superheated steam or inert gas at 200-350℃. Exposure to gases that produce explosive mixtures).
The degassed substances can be regenerated by the decompression removal method.
Package
Packed in iron drums, (according to the product model) net weight 125kg, 135kg, 140kg, or according to user needs.
Why Choose us
1. Long history and stable production We have produced chelating agents products for many years., 80% of the products are for export . we have more than 10 years chemical exporting experience and also we provide good and stabilized factory price.
2. Strict quality control system We have strict quality control system, All of our technicist are professional , they are strictly on quality control.
3. Free samples available If you have purchase intention, contact us, we send out sample. We promise the same quality as bulk quantity .
4. Quick response 24h on line and prompt reply
5. Competitive price You can visit our factory anytime,also you can take samples, we are sure that our price is very competitive in this market and quality is the best
Product Pictures
Factory information
Shanghai Xuefeng Molecular Sieve Co., Ltd. adopts the most advanced and fully automated assembly line molecular sieve production technology in China, and has positions for dosing, kneading, extrusion, drying, roasting and packaging. The main equipment includes pelletizing machine, hardening cylinder, kneader, extruder, belt dryer, rotary roasting furnace, vibrating screen, scale and other ancillary facilities. The production process parameters are all automatically controlled, and there is no paper recorder attached. , The results of the process parameters are comprehensively recorded, and at the same time, the operators of each position shall manually record the parameters every hour to ensure the traceability of the operation process. At the same time, the company pays attention to the inspection of intermediate products, and has set up sampling points for intermediate products in the ingredients, extrusion molding, and drying positions to ensure that the intermediate products meet the specified quality requirements.
